HX-400: 40,000 rpm Direct-Drive Spindle
A direct-drive, liquid-cooled motor spindle for 5-axis machining centers.
The HX-400 High-Speed CNC Spindle from Hanil Precision delivers a maximum speed of 40,000 rpm with a rated power of 22 kW (S1). Peak torque is 14.5 Nm.
- Direct-drive motor spindle
- Liquid-cooled design
- Built for 5-axis machining centers
- High-speed, high-power performance
HX-400 in Numbers
40,000
Maximum speed
1,860
Machines with HX-400 installed
14
Countries served
21,000
Documented MTBF
6,500
Annual production capacity
1994
Year Hanil Precision began manufacturing precision spindles
1.HX-400 at a Glance
| Product | HX-400 High-Speed CNC Spindle |
|---|---|
| Type | Direct-drive, liquid-cooled motor spindle |
| Designed for | 5-axis machining centers |
| Maximum speed | 40,000 rpm |
| Rated power | 22 kW (S1) |
| Tool interface | HSK-A63 |
| Manufacturer | Hanil Precision Co., Ltd. |
| Spindle production since | 1994 |
| Production plants | Two ISO 9001:2015 certified plants in Changwon, Korea |
| Standard lead time | 8 weeks ex-works Changwon |
[Source 3]
- “The HX-400 is a direct-drive,…”p. 1
- “Standard lead time is 8 weeks ex-works…”p. 2
- “Rated power (S1 / S6-40%) · 22 kW / 30…”p. 1
2.Built for Precision at 40,000 rpm
| Hybrid ceramic bearings | The HX-400 runs on hybrid ceramic angular contact bearings, oil-air lubricated. |
|---|---|
| Rigidity and runout | Radial runout at taper is ≤ 1.0 µm, measured 50 mm from the nose, and axial stiffness is 190 N/µm. |
| Balanced and load-tested | All HX-series spindles are balanced to ISO 1940 grade G0.4 and tested for 24 hours under load before shipment. |
| Manufacturing heritage | Hanil Precision has manufactured precision spindles since 1994. It operates two ISO 9001:2015 certified plants in Changwon, Korea, with an annual production capacity of 6,500 spindle units. |
3.HX-400 Options and Accessories
Vibration sensor kit
Tri-axial accelerometer with 24-bit data acquisition; supports predictive maintenance via OPC UA
Through-spindle coolant
Coolant delivery through the spindle, with a rotary union rated for 40,000 rpm
- Pressure up to 70 bar
Tool clamp monitoring
Analog position sensor with 3-state output (clamped / unclamped / no tool)
Extended warranty
Coverage for 36 months or 12,000 operating hours, whichever comes first
4.HX-400 Technical Specifications
| Maximum speed | 40,000 rpm (continuous) |
|---|---|
| Rated power (S1 / S6-40%) | 22 kW / 30 kW at 12,000 rpm |
| Peak torque | 14.5 Nm (S6-40%) |
| Tool interface | HSK-A63 (DIN 69893) |
| Cooling | Liquid, 12 L/min, inlet 20 ± 1 °C |
| Weight | 68 kg without tool |
| Dimensions (Ø × L) | Ø200 × 585 mm |
| Operating temperature | 5 – 40 °C ambient |
| Noise level | ≤ 72 dB(A) at 40,000 rpm, 1 m |
| Calibration | Every HX-400 ships with a calibration certificate traceable to KRISS (Korea Research Institute of Standards and Science) |
| Compliance | CE Machinery Directive 2006/42/EC; UL 61800-5-1 recognition for the North American market |
[Source 2]
- “Rated power (S1 / S6-40%) · 22 kW / 30…”p. 1
- “Every HX-400 is shipped with a…”p. 2
5.Certifications and Standards
ISO 9001:2015
Two certified plants in Changwon, Korea
CE Machinery Directive 2006/42/EC
The HX-400 spindle complies with this directive
UL 61800-5-1
Recognition for the North American market
KRISS calibration certificate
Shipped with every HX-400, traceable to KRISS (Korea Research Institute of Standards and Science)
ISO 1940 grade G0.4
All HX-series spindles are balanced to this grade
6.Proven in the Field
Installed base, benchmark results and typical applications for the HX-400
| 6.1Installed base | HX-400 has been installed in 1,860 machines across 14 countries since its launch in 2021. |
|---|---|
| 6.2Field reliability | Documented MTBF of 21,000 hours, based on field data from 312 units monitored over 36 months. |
| 6.3Cycle time on thin-wall aluminum components | Customers report a 27% reduction in cycle time compared with 24,000 rpm spindles, based on a 2025 benchmark study conducted with 8 customers. |
| 6.4Warranty returns | 0.6% warranty return rate across all HX-series units in fiscal 2025. |
| 6.5Aluminum aerospace structural parts | A typical application for the HX-400. |
| 6.6Medical implant machining | Typical application for machining titanium Ti-6Al-4V. |
| 6.7Mold and die finishing | Typical application with tools down to 0.3 mm diameter. |
